Amplifiers
for A.C. Servo Motors
|
MODEL
|
OUTPUT
POWER
|
OUTPUT
VOLTAGE
|
OUTPUT
FREQUENCY
|
INPUT
SIGNAL
FREQUENCY
|
INPUT
IMPEDANCE
|
GAIN
|
POWER
REQUIRED
|
TEMPERATURE
RANGE
|
200-HP
|
3.5W
|
40
VCT
|
400
Hz
|
400
Hz
|
10K
|
2,500
|
28VDC
|
-55ºC
+ 125ºC
|
200-5
|
3.5W
|
40
VCT
|
400
Hz
|
400
Hz
|
10K
|
5,000
|
28VDC
|
-55ºC
+ 125ºC
|
930
|
3.5W
|
40
VCT
|
400
Hz
|
400
Hz
|
250K
|
2,000
|
28
VDC
|
-55ºC
+ 125ºC
|
200-8
|
3.5W
|
40
VCT
|
400
Hz
|
400
Hz
|
10K
|
2,500
|
115
V
400 Hz
|
-55ºC
+ 125ºC
|
216B
|
6W
|
40
VCT
|
60
Hz
|
60
Hz
|
10K
|
1,000
|
28VDC
|
-55ºC
+ 85ºC
|
140
|
6W
|
40
VCT
|
400
Hz
|
400
Hz
|
50K
|
1,000
|
28VDC
|
-55ºC
+ 125ºC
|
141
|
6W
(90º)
|
40
VCT
|
400
Hz
|
400
Hz
|
30K
|
1,000
|
28VDC
|
-55ºC
+ 125ºC
|
416-3
|
16W
|
40
VCT
|
400
Hz
|
400
Hz
|
10K
|
1,000
|
28VDC
|
-55ºC
+ 71ºC
|
416A/D
|
16W
(0º/90º)
|
40
VCT
|
400
Hz
|
400
Hz (2)
|
10K
|
1,000
|
28VDC
|
-55ºC
+ 100ºC
|
416M
|
16W
(90º)
|
40
VCT
|
400
Hz
|
DC
(2)
|
10K
|
200
|
28VDC
115
V
400 Hz
|
-55ºC
+ 125ºC
|
159
|
16W
|
40
VCT
|
60
Hz
|
60
Hz
|
10K
|
1,000
|
28VDC
|
-55ºC
+ 100ºC
|
159A/D
|
16W
(0º/90º)
|
40
VCT
|
60
Hz
|
DC
|
100K
|
1,000
|
28VDC
|
-55ºC
+ 100ºC
|
174
|
40W
(90º)
|
40
VCT
|
60
Hz
|
60
Hz
|
20K
|
1,000
|
28VDC
|
|
956B
|
40W
(90º)
|
40
VCT
|
400
Hz
|
400
Hz
|
10K
|
1,000
|
28VDC
|
-55ºC
+ 100ºC
|
956C
|
40W
(90º)
|
40
VCT
|
400
Hz
|
DC
|
10K
|
500
|
28VDC
115
V
400 Hz
|
-55ºC
+ 100ºC
|
170-1
|
100W
(90º)
|
40
VCT
|
400
Hz
|
400
Hz
|
10K
|
100
|
28VDC
|
-55ºC
+ 85ºC
|
170-3
|
180W
(90º)
|
36
VCT
|
400
Hz
|
400
Hz
|
10K
|
1,000
|
28VDC
|
-55ºC
+ 85ºC
|
MODIFICATIONS
to gain input impedance, signal frequency, and power level are
available. Matching transformers for driving motors at other
volatages in stock.
|
Linear
D.C. Power Amps
|
MODEL
|
OUTPUT
POWER
|
OUTPUT
VOLTAGE
|
OUTPUT
FREQUENCY
|
INPUT
SIGNAL
FREQUENCY
|
INPUT
IMPEDANCE
|
GAIN
|
POWER
REQUIRED
|
TEMPERATURE
RANGE
|
916
|
110W
(Short proof)
|
±
20V
|
DC
to 1 KHz
|
DC
to 1 KHz
|
10K
|
3x105
|
28VDC
± 15VDC
|
-55ºC
+ 100ºC
|
916-208
|
650W
(Short proof)
|
±
55V
|
DC
to 1 KHz
|
DC
to 1 KHz
|
10K
|
2A
/ V
|
55VDC
|
-55ºC
+ 100ºC
|
916-300
|
300W
(Short proof)
|
±
20V
|
DC
to 1 KHz
|
DC
to 1 KHz
|
10K
|
3x105
|
28VDC
± 15VDC
|
-55ºC
+ 100ºC
|
918-108
|
240W
(Short proof)
|
±
25V
|
DC
to 10KHz
|
DC
to 10KHz
|
10K
|
Prog
|
28VDC
- 15VDC
|
-55ºC
+ 85ºC
|
918-108B
|
240W
(Short proof)
|
±
25V
|
DC
to 10KHz
|
DC
to 10KHz
|
10K
|
Prog
|
28VDC
- 15VDC
|
-55ºC
+ 86ºC
|
987-17
|
200W
(Short proof)
|
±
20V
|
DC
to 1 KHz
|
DC
to 1 KHz
|
10K
|
10
|
28VDC
± 15VDC
|
-55ºC
+ 71ºC
|
980-1S
|
500W
(Short proof)
|
±
50V
|
DC
to 1 KHz
|
DC
to 1 KHz
|
10K
|
100
|
115V
50-400
Hz
|
-55ºC
+ 71ºC
|
980-32
|
500W
(Short proof)
|
±
75V
|
DC
to 1 KHz
|
DC
to 1 KHz
|
10K
|
100
|
115V
50-400
Hz
|
-55ºC
+ 71ºC
|
980-28
|
1350W
(Short proof)
|
±
52V
|
DC
to 1 KHz
|
DC
to 1 KHz
|
10K
|
100
|
208V
60/400Hz
3 Phase
(1 Phase Available)
|
-55ºC
+ 71ºC
|
980-27
|
3000W
(Short proof)
|
±
95V
|
DC
to 1 KHz
|
DC
to 1 KHz
|
10K
|
100
|
105
VDCand AC Fan Power
|
-55ºC
+ 71ºC
|
MODIFICATIONS
to gain input impedance, signal frequency, power level and
operating temperature.
|
Synchro
Amplifiers
|
MODEL
|
OUTPUT
POWER
|
OUTPUT
VOLTAGE
|
OUTPUT
FREQUENCY
|
INPUT
SIGNAL
FREQUENCY
|
INPUT
IMPEDANCE
|
GAIN
|
POWER
REQUIRED
|
TEMPERATURE
RANGE
|
180-1
|
5W
|
11.8V
Synchro
|
400Hz
|
400Hz
SIN/COS
|
50K
|
3'
|
±
15VDC
|
-55ºC
+ 100ºC
|
180-2
|
5W
|
90V
Synchro
|
400Hz
|
400Hz
SIN/COS
|
50K
|
3'
|
±
15VDC
|
-55ºC
+ 100ºC
|
180-3
|
5W
|
90V
Synchro
|
50/60Hz
|
50/60Hz
SIN/COS
|
50K
|
3'
|
±
15VDC
|
-55ºC
+ 100ºC
|
Modulators
and Demodulators
|
MODEL
|
OUTPUT
POWER
|
OUTPUT
VOLTAGE
|
OUTPUT
FREQUENCY
|
INPUT
SIGNAL
FREQUENCY
|
INPUT
IMPEDANCE
|
GAIN
|
POWER
REQUIRED
|
TEMPERATURE
RANGE
|
312
|
Full Wave
|
10V
|
DC
|
60Hz
|
10K
|
10
|
28 VDC
115V
Reference
|
-55ºC
+ 125ºC
|
334-1
|
Full Wave
|
50V
|
DC
|
400Hz
|
10K
|
180
|
28VDC
115V
400Hz
|
-55ºC
+ 125ºC
|
334-2
|
Full Wave
|
30V
|
DC
|
400Hz
|
125K
|
1
|
115V
400Hz
|
-55ºC
+ 71ºC
|
312-1
|
Full Wave
|
10V
|
DC
|
600Hz to 5000Hz
|
10K
|
10
|
28 VDC
115V
Reference
|
-55ºC
+ 125ºC
|
350-1
|
Full Wave
|
15V
|
DC
|
400Hz
|
10K
|
10
|
28VDC
115V
400Hz
|
-55ºC
+ 125ºC
|
Modifications to gain,
output voltage and input impedance available.
|
|
